Powerful and compact. The hand-held power tool for breakthroughs in masonry and concrete inspires with particularly ergonomic handling and consistently strong performance.
The hand-held core drilling machine for wet drilling with a spade handle impresses with its particularly compact, light and ergonomic design, which promotes effortless working. The adjustable clamping handle enables easy and controlled operation during hand-guided core drilling. The high-torque 230 V motor achieves a nominal power of 2,000 W and enables core drilling in masonry up to 200 mm diameter and in concrete up to 150 mm diameter.
The powerful and durable core drilling system works with a diamond drill bit and is suitable for a variety of tasks such as wall breakthroughs, wall drilling and floor drilling. The hand-held Core drill is an extremely efficient tool for a wide range of applications in installation and fastening technology applications. Three gear ranges allow optimal speed selection, matched to the core drilling diameter. Precise horizontal and vertical core drilling is guaranteed by the three integrated water levels. The hand-operated core drilling machine is equipped as standard with the extremely effective MULTI-TRONIC. The sophisticated, tried and tested overload protection system ensures maximum ease of use and a long life for core drilling motor. One electronic and one mechanical overload clutch and additional thermal overload protection guarantee the maximum safety in demanding long-term use.
Ergonomics and power impress with this robust, hand-held core drilling system. Explore the features of the CDM 20 S:
Key Features
Compact, lightweight and ergonomic design
Simple, controlled operation during hand-guided core drilling using universal clamping handle
Three speed gear box allows optimum speed selection
FAQs
Why does choosing the right CDM 20 S matter on a UAE project? An under-specified or poorly maintained cdm 20 s slows a schedule down and is a common cause of on-site incidents, while a correctly specified, well-maintained unit keeps output consistent and meets the safety and quality standards expected on Abu Dhabi and Dubai construction and industrial sites.
How do I get pricing for the CDM 20 S? Pricing for the CDM 20 S depends on the exact specification and quantity required — submit a quote request through the enquiry form on this page or contact Sparkline Group directly, and our sales team will respond with a formal quotation.
Is the CDM 20 S available for delivery across the UAE and GCC? Yes — Sparkline Group supplies and delivers the CDM 20 S to project sites across Abu Dhabi, Dubai, Sharjah and the wider UAE, with support for GCC-wide delivery on request.
Does the CDM 20 S meet UAE compliance and safety standards? Yes — the CDM 20 S is supplied to meet the safety and quality standards expected on UAE construction and industrial sites, and Sparkline Group's technical team can advise on the certification or documentation your project requires.
Does Sparkline Group provide after-sales support for the CDM 20 S? Yes — Sparkline Group backs the CDM 20 S with genuine spare parts, technical guidance and after-sales support across the UAE, so the equipment stays productive well beyond the point of sale.
